Family image shown — colour and finish may differ. Part photo coming soon.
Sealproof® Conduit and Connectors · Non-Metallic Liquid Tight Connectors
Screw-On Connector, 90 Degree Sweep, 1/2" — Bulk, 250 pcs/box
Part no.
8518P
UPC 658746885193 Carton 250 pcs - Liquid-tight · for LFNC-B conduit
A 90° non-metallic liquid-tight connector — terminates Type B liquid-tight flexible conduit (LFNC-B) into a box or enclosure with a sweeping 90° turn for easier pulls.
- Type
- 90° connector
- For
- Non-metallic liquid-tight flexible conduit, Type B
- Material
- PVC — one-piece, UV-rated
- Pack
- 250 per carton
Request a quote
Questions? 1-800-394-3665 · sales@superflex.com
Downloads & documents
Features
- Listed under the Underwriter's Laboratories
- Available in 1/2 inch and 3/4 inch trade size
- UL and CUL listed
- PVC construction produced from UV rated material for long outdoor life
- Attractive one-piece design
- No disassembly required; simply screw the connector unto the conduit
- Time and cost saving benefits over other brands
- Design allows superior liquid-tight seal and optimum pull strength without compression nut
- Ideal for conduit assemblies and installers
- "0" Ring and steel locknut included
- Patented
Specifications
- Part number
- 8518P
- UPC / GTIN-12
- 658746885193
- Material
- PVC
- Carton quantity
- 250
- Brand
- Sealproof — a Superflex Ltd. brand
Dimensions
| A — overall height | 1.875 in |
|---|---|
| B — thread length | 0.500 in |
| C — overall reach | 3.125 in |
A overall length (height on the 90° sweep) · B thread length · C body diameter (reach on the 90° sweep). Nominal, in inches.
All Non-Metallic Liquid Tight Connectors About this family →
Item No. | Description | Size | Color | UPC | Pkg | Spec sheet | |
|---|---|---|---|---|---|---|---|
3/8" | Black | 658746884004 | 100 | ||||
3/8" | Gray | 658746884011 | 100 | ||||
1/2" | Black | 658746884028 | 100 | ||||
1/2" | Gray | 658746884035 | 100 | ||||
3/4" | Black | 658746884042 | 100 | ||||
3/4" | Gray | 658746884059 | 100 | ||||
1" | Black | 658746884066 | 50 | ||||
1" | Gray | 658746884073 | 50 | ||||
1-1/4" | Black | 658746884080 | 25 | ||||
1-1/4" | Gray | 658746884097 | 25 | ||||
1-1/2" | Black | 658746884103 | 10 | ||||
1-1/2" | Gray | 658746884110 | 10 | ||||
2" | Black | 658746884127 | 10 | ||||
2" | Gray | 658746884134 | 10 | ||||
3/8" | Black | 658746884158 | 100 | ||||
3/8" | Gray | 658746884165 | 100 | ||||
1/2" | Black | 658746884172 | 100 | ||||
1/2" | Gray | 658746884189 | 100 | ||||
3/4" | Black | 658746884196 | 100 | ||||
3/4" | Gray | 658746884202 | 100 | ||||
1" | Black | 658746884219 | 50 | ||||
1" | Gray | 658746884226 | 50 | ||||
1-1/4" | Black | 658746884233 | 25 | ||||
1-1/4" | Gray | 658746884240 | 25 | ||||
1-1/2" | Black | 658746884257 | 10 | ||||
1-1/2" | Gray | 658746884264 | 10 | ||||
2" | Black | 658746884271 | 10 | ||||
2" | Gray | 658746884288 | 10 | ||||
1/2" | Gray | 658746885032 | 100 | ||||
658746885049 | 500 | ||||||
3/4" | Gray | 658746885056 | 100 | ||||
658746885063 | 500 | ||||||
1/2" | Gray | 658746885186 | 100 | ||||
3/4" | Gray | 658746885209 | 100 | ||||
658746885216 | 250 | ||||||
1/2" | 658746886039 | 100 | |||||
3/4" | 658746886053 | 100 | |||||
1/2" | Black | 658746886176 | 100 | ||||
1/2" | Gray | 658746886183 | 100 | ||||
3/4" | Black | 658746886190 | 100 | ||||
3/4" | Gray | 658746886206 | 100 |
Need pricing on Screw-On Connector, 90 Degree Sweep, 1/2″ — Bulk, 250 pcs/box?
Send us the part numbers and quantities. Our sales team in Elizabeth, NJ will come back to you with pricing and availability.
